The color coordinates L*,a*,b* (CIELAB) are computed according to DIN 5033. They are based on X,Y,Z (see above).



The following equations are used:





If the arguments of the cubic roots are smaller than 0.008856 then the cubic root is replaced by the expression 7.787*argument+16/116 .
